IEC 61076-2-104 M8 Female Connectors Field Wireable Assembled 3 Pin A Code

Name: IEC 610762104 M8 Female Connectors Field Wireable Assembled 3 Pin A Code
Brand: KRONZ
Price: 1 USD

Wholesale IEC 61076-2-104 M8 Female Connectors Field Wireable Assembled 3 Pin A Code from china suppliers

Model Number : H0803F-0

Place of Origin : Guangdong, China

MOQ : 50 pieces

Price : Negotiable

Brand Name : KRONZ

Certification : CE

Payment Terms : T/T,Western Union,MoneyGram

Supply Ability : 100000 pieces per month

Delivery Time : 5-8 working days

Packaging Details : Polybag packing

Type : Contactor

Product name : Cable Connector

Contact nut material : Brass, nickle-plated

Cable Outlet : Straight

Seal material : FPM and FKM

Contact resistance : ≤ 5mΩ

Pollution degree : 3

Working temperature : -25~+85℃

Contact Now

IEC 61076-2-104 M8 Connector Field-wireable Assembly Connectors 3 Pin A Code Female

The M8 pre-molded cable connector plays an irreplaceable role in automotive production. It connects robot sensors to the control unit, transmitting signals and data through these connectors to enable precise operations in tasks such as welding, painting, and assembly. With its high flexibility, the M8 connector ensures the accuracy of automated control, thereby driving the smooth implementation of fully automated production processes.

Features:

Field-Wireable Design:

Screw termination (0.14-1.5mm² wire range)
Tool-free assembly for easy installation

3-Pin A-Coding:

Standard sensor/actuator pin configuration
Prevents mismating with other coding types

Durable Construction:

PBT thermoplastic housing
Nickel-plated brass contacts

Reliable Performance:

IP67 protection rating
Vibration-resistant threaded coupling (M8x1)
Operating temperature: -25°C to +85°C

Electrical Specifications:

Rated voltage: 30V AC/DC
Current rating: 4A per contact
Contact resistance: <10mΩ
Insulation resistance: >100MΩ

Product image and dimension

IEC 61076-2-104 M8 Female Connectors Field Wireable Assembled 3 Pin A Code

Technical Parameters

Standard	IEC 61076-2-104
Contact nut material	Brass, nickle-plated
Contact surface material	Brass, gold-plated
Contact carrier material	PA, black
Housing material	PBT/PA, black
Seal material	FPM/FKM
Insulation resistance	≥100MΩ
Contact resistance	≤5mΩ
Pollution degree	3
Ambient temperature	-25~+85℃
Mating cycles	>100
Degree of protection	IP67

Pin assignment	Connection method	Coding	Rated current	Voltage	Cable outlet	External cable diameter	Model No.
	Screw connection	A	3A	60V	Straight	3.5-5mm	H0803F-0
